Ekinex EK-BJ1-TP-MSTP, Gateway BACnet MS/TP server - KNX TP
The ekinex® BACnet - KNX Gateway performs a protocol conversion between a BACnet and a KNX TP network.
DESCRIPTION
Device working as a gateway (protocol conversion) between a BACnet MS/TP (Master Slave Token Passed) network on serial RS485 line and a KNX (TP) network. Server function on the BACnet MS/TP network. Mounting in distribution board on EN 60715 rail (4 modular units, each 18 mm). To be used in KNX installations for home and building automation.
FUNCTIONS / CHARACTERISTICS
BACnet side
• Electrically insulated RS485 serial communication port, 1-way DIP switch to activate the line terminator (120 Ohm)
• BACnet communication
• Communication speed from 1200 to 115200 baud
• BACnet register exchange
• Volatile support memory with "BACnet image" buffer of 1440 bytes
KNX side
• KNX TP (twisted pair) 9600 baud communication port, electrically insulated from power supply
• Volatile support memory with "image KNX" buffer of 1440 bytes
CONFIGURATION AND COMMISSIONING
A detailed description of the parameters can be found in the application manual of the device. Configuration and commissioning require the application software CGEKBJ1TP.exe
